XVR 4 canali Longse

DVR/NVR

XVR Longse XVRT3004C

XVR Longse XVRT3004C

72.50 €(IVA incl.)

Aggiungi

SPECIFICHE

System

Main Processor - MC6630

Operating System - Embedded LINUX

Video

Input - Normal Mode: Analog: 4*(TVI/AHD: 5M@12fps; AHD/TVI/CVI: 4M@15fps; AHD/TVI: 3M@18fps; AHD/TVI/CVI: 1080P/720P; Analog: 960H)

Analog+Network: 2*Analog(TVI/AHD: 5M@12fps; AHD/TVI/CVI: 4M@15fps; AHD/TVI: 3M@18fps; AHD/TVI/CVI: 1080P/720P; Analog: 960H)+4*network(MAX 2MP)

Network: 9*5MP/4MP/3MP/1080P/960P/720P(Total incoming bandwidth ≤48M)

Input - 4CH BNC

Signal Type - Analog/AHD/CVI/TVI 2.0/TVI 3.0/Network

Output - 1HD,1 VGA

Audio

Input - 1 Channel, RCA, support AOC

Two-way Audio - NO

Output - 1 Channel, RCA

Alarm

Sensor Input - NO

Output - NO

Motion Detection - 4 Channel(max 9 Channel in pure network mode)

Trigger Events - Recording, Email, Screen tips, Buzzer, Push notifications(motion detection)

Email Alarm - Send Image to The Designated E-mail

AI Function

Human Detection - YES

PTZ

Interface - RS485

Protocol - Pelco-D, Pelco-P

Baud Rate - 110~921600

Address - 0~255

Display

VGA - Resolution: 1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,1024 × 768/60Hz

HD Output - Resolution:1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,1024 × 768/60Hz

Display Split - 9 Channel/4 Channel / 1Channel

Privacy Masking - 3 Rectangular Zones (Each camera)

OSD - Camera title, Time, Video loss, Alarm, Motion detection, Recording

Recording

Video Compression - H.265/H.264

Audio Compression - G.711U/G.711A

Resolution - 5MP_Lite(1296×1952),4MP_Lite(1280×1440),3MP_Lite(1024×1536),1080N(960×1080),720P(1280×720),960H(P:960×576/N:960×480)

Video Quality - Lowest/Low/Ordinary/Good/Better/Best

Record Rate - Analog: PAL:5MP_Lite(1296×1944 4*8fps),4MP_Lite(1280×1440 4*15fps),3MP_Lite(1024×1536 4*18fps),1080N(960×1080 4*18fps),720P(1280×720 4*20fps), 960H(960×480 4*25fps)

NTSC: 5MP_Lite(1296×1944 4*8fps),4MP_Lite(1280×1440 4*15fps),3MP_Lite(1024×1536 4*18fps),1080N(960×1080 4*18fps),720P(1280×720 4*20fps), 960H(960×480 4*30fps)

Pure IP(H.265):

PAL: 5MP@8×25fps,4MP@9x25fps,3MP@9×25fps,1080P@9×25fps,960P@9×25fps,720P@9×25fps,D1@9×25fps

NTSC: 5MP@8×30fps,4MP@9×30fps,3MP@9×30fps,1080P@9×30fps, 960P@9×30fps, 720P@9×30fps, D1@9×30fps

Record Mode - Manual\Timer\Motion Detection

Playback & Backup

Decode Capability - 2CH 1080P@30fps

Sync Playback - Pure Analog: 4CH 960H@25fps, 2CH 720P@20fps, 2CH 1080N@18fps, 1CH 5M_LITE@8fps, 1CH 4M_LITE@15fps, 1CH 3M_LITE@18fps

Mixture mode: 4CH 720P@25fps, 2CH 1080P@25fps, 1CH 5M_LITE@8fps, 1CH 4M_LITE@15fps, 1CH 3M_LITE@18fps

Pure Network: 4CH*720P@25fps, 2CH 1080P@25fps, 1CH 5MP@25fps

Remote Playback - 1 Channel

Search Mode - ALL, Channel, Manual, Time, Date, Motion Detection

Playback Functions - Play, Pause, Stop, Fast play, Slow play, Rewind, Single frame forward/back, Digital Zoom, Full screen

Smart Phone Playback - 4 Channel

Backup Mode - USB Device(with fomat FAT 32 )/Network/FTP

Network

Interface - 1 RJ45 10M/100M Adaptive Ethernet Interface

Network Functions - TCP/IP, HTTP, UPnP, DNS, NTP, SMTP,DHCP, FTP, DDNS, RTP, RTSP, RTCP

DDNS - Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE,HDPROVN

Web Browser - Edge,IE8-11, Google Chrome , Firefox ,Safari

CMS Software - Support Windows 7/ Windows 8/Windows 10

Extra Stream - CIF/D1(1~25fps)

Smart Phone - iPhone, ipad, Android ,Android pad

Hard Disk Driver

Interface Type - 1 SATA Interface

Capacity - 1 SATA Hard Disk (2.5″/3.5″ SATA, Up to 8TB)

General

Language - Simplified Chinese, Traditional Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Japanese, German, French, Portuguese,

Turkic, Spanish, Italian, Hungarian, Romanian, korean, Dutch, Greek, Vietnamese

UTC Control - YES

USB Interface - 2 USB 2.0 Interfaces

Power consumption - DC 12V/2A ≤4W (Without Hard Disk)

Working Environment - -10~55℃/10~90%

Dimension (W×D×H) - 260*215*43(mm)

Weight - 2kg (Without HDD)
